GP7142-5121
WARNING: This product might contain a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
| Specification | US | Metric |
|---|---|---|
| Flow | 38.4 GPM | 145.2 L/min |
| Maximum Discharge Pressure | 2600 PSI | 180 bar |
| Crankshaft Speed | 700 RPM | |
| Power | 69.0 HP | 51.5 KW |
| Max Temperature | 140 °F | 60 °C |
| Inlet Port Size | (2) 2-1/2" BSP | |
| Discharge Port Size | (2) 1-1/4" BSP | |
| Plunger Diameter | 1.65 in. | 42 mm |
| Stroke | 2.05 in. | 52 mm |
| Maximum Inlet Pressure | 145 PSI | 10 bar |
| Crankshaft Diameter | 1.89 in. | 48 mm |
| Crankshaft Rotation | Top of Pulley Towards Manifold | |
| Key Width | 0.55 in. | 14 mm |
| Crankshaft Mounting | Either Side | |
| Crankcase Oil Capacity US | 1.6 gal | 6.0 L |
| Weight | 474 lbs. | 215 kg |
| NPSHR | 31.8 Ft.-head | 9.7 mWs |
The repair kits listed to the right are available for this pump. If you need further information about these repair kits, or have questions about other specific parts for your pump, please contact you local Giant distributor or contact Giant customer service.
| ITEM# | PART# | DESCRIPTION | Qty. |
|---|---|---|---|
| Plunger Packing Kit – Part #09766-0121 | |||
| 38A | 13156-0001 | O-Ring | 3 |
| 38B | 13141-0001 | O-Ring | 3 |
| 39A | 0480-0020 | Grooved Seal Assembly | 3 |
| 39C | 05474 | Clip Ring | 3 |
| 40 | 03513 | Guide Ring | 3 |
| 41 | 03518 | Support Ring | 3 |
| 42 | 03519 | Triple Coiled Ring | 3 |
| Valve Assembly Kit – Part #000 | |||
| 51 | 03436 | Valve Assembly | 6 |
| 56A | 07658-0001 | O-Ring | 3 |
| 56B | 07635 | Support Ring | 3 |
| 56C | 13166 | Support Ring | 3 |
| 56D | 07653-0001 | O-Ring | 3 |
| Oil Seal Kit – Part #09221 | |||
| 32 | 07624 | Radial Shaft Seal | 3 |
| 33A | 07627 | O-Ring | 3 |
Horsepower Specifications
| RPM | GPM | 1000 PSI | 1500 PSI | 2000 PSI | 2600 PSI |
|---|---|---|---|---|---|
| 350 | 19.2 | 13.2 | 19.9 | 26.5 | 34.4 |
| 400 | 21.9 | 15.1 | 22.7 | 30.2 | 39.3 |
| 500 | 27.4 | 18.9 | 28.4 | 37.8 | 49.1 |
| 600 | 32.9 | 22.7 | 34.0 | 45.4 | 59.0 |
| 700 | 38.4 | 26.5 | 39.7 | 53.0 | 68.9 |
