GP5132GBHS-5100
WARNING: This product might contain a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
| Specification | US | Metric |
|---|---|---|
| Flow | 27.7 GPM | 104.9 L/min |
| Maximum Discharge Pressure | 3000 PSI | 200 bar |
| Crankshaft Speed | 1000 RPM | |
| Power | 57.4 HP | 42.8 KW |
| Intermittent Flow | 40.0 GPM | 151.0 L/min |
| Intermittent Discharge Pressure | 3000 PSI | 200 bar |
| Intermittent Crankshaft Speed | 1000 RPM | |
| Max Temperature | 140 °F | 60 °C |
| Inlet Port Size | (3) 1-1/2"NPT | |
| Discharge Port Size | (2) 1" NPT | |
| Plunger Diameter | 1.26 in. | 32 mm |
| Stroke | 1.81 in. | 46 mm |
| Maximum Inlet Pressure | 145 PSI | 10 bar |
| Crankshaft Bore | SAE-C Spline 14T 12/24DP | |
| Crankshaft Rotation | Hydraulic Gear towards back of pump | |
| Crankshaft Mounting | Either Side | |
| Crankcase Oil Capacity US | 1.3 gal | 5.0 L |
| Weight | 269 lbs. | 122 kg |
| Manifold Material | 316 Stainless Steel | |
| Crankcase Material | Spheroidal Cast Iron |
The repair kits listed to the right are available for this pump. If you need further information about these repair kits, or have questions about other specific parts for your pump, please contact you local Giant distributor or contact Giant customer service.
| ITEM# | PART# | DESCRIPTION | Qty. |
|---|---|---|---|
| Plunger Packing Kit – Part #09879 | |||
| 35A | 08183 | O-Ring | 6 |
| 35B | 13286 | O-Ring | 3 |
| 36 | 13025 | Grooved Ring | 3 |
| 37A | 07700 | O-Ring | 3 |
| 37B | 07653 | O-Ring | 3 |
| 40 | 13027 | V-Sleeve | 6 |
| Inlet Valve Kit – Part #09231-0100 | |||
| 46A | 06577 | O-Ring | 3 |
| 46C | 13304-0100 | Valve Seat | 3 |
| 46D | 13306-0100 | Valve Plate | 3 |
| 46E | 13307 | Valve Spring | 3 |
| 46F | 13308 | Spring Tension Cap | 3 |
| Discharge Valve Kit – Part #09232-0100 | |||
| 47A | 13289-0100 | O-Ring | 3 |
| 47C | 13313 | Valve Seat | 3 |
| 47D | 13306-0100 | Valve Plate | 3 |
| 47E | 13307 | Valve Spring | 3 |
| 47F | 13308 | Spring Tension Cap | 3 |
| Oil Seal Kit – Part #09230 | |||
| 31 | 13284 | Oil Seal | 3 |
Horsepower Specifications
| RPM | GPM | 1000 PSI | 1500 PSI | 2000 PSI | 3000 PSI |
|---|---|---|---|---|---|
| 500 | 13.9 | 9.6 | 14.7 | 19.2 | 28.8 |
| 600 | 16.6 | 11.5 | 17.2 | 22.9 | 34.4 |
| 700 | 19.4 | 13.4 | 20.1 | 26.8 | 40.1 |
| 800 | 22.2 | 15.3 | 23.0 | 30.6 | 45.9 |
| 900 | 24.9 | 17.2 | 25.8 | 34.4 | 51.58 |
| 1000 | 27.7 | 19.1 | 28.7 | 38.2 | 57.3 |
